300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Name: 3002100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press
Brand: RUNNING
Price: 1 USD

Quality 300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press for sale

Brand Name : RUNNING

Model Number : 300mm - 2100mm

Certification : ISO9001 CE

Place of Origin : QINGDAO CHINA

MOQ : 1 SET

Price : Negotiable

Payment Terms : T/T, L/C

Supply Ability : 5000 sets/year

Delivery Time : 7 working days

Packaging Details : FCL/LCL

Condition : New

Application : PVC/PU belt jointing

Belt : PVC PU PVK belt

Material : Aluminum Alloy

Applied Belt Width : 300 Mm- 2100mm Or Customized

Heating method : Electricity heating

Cooling method : Air cooling

Voltage : 220V 380V Or Customized

Warranty : 2 years

After-sales Service : Overseas Service Center

Contact Now

Splicing Press Air Cooling PU PVC Conveyor Belt Jointing Vulcanizer

This air cooled press is all components integrated into the tool, allowing users plug it simply into electricity and it is ready for use. Fast and Portable Splicing, can bring to anywhere easily.
There are different models of air cooled press series, for width from 24″ (300 mm) to 84″ (2100 mm)

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Features of PVC/PU belt joint press:

Used for splicing PVC PU PVK Printing Blankets belt etc. thermoplastic belt materials
Portable Conveyor Belt Splice Press, light weight and with flight case as standard packing, is easily removed to any where for job site use.
Fast Splicing: include heating time and cooling time, no more than 12min.
Temperature up to 200 ºC (392 ºF)
All in one design: The press has an integrated air-cooling system and also air compressor inside. To ensures that the belt is quickly cooled down and auto press on, without water pump or additional air compressor.
Easy to use and assemble.
Light weight aluminum construction
Reliable and automatic Temperature Control with time control. High quality Eurotherm controller.
Air pressure controller (set the air pressure and display the current pressure), High quality SMC controller.
Voltage: 220V or 380V, if special voltage pls freely to inform us, like 110V (only under 1200mm, include 1200) etc.
If used in workshop, pneumatic lifting steel stand is optional.

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Application:

The PVC/PU belt joint press machine is used for welding&jointing PVC/PU belt into endless belt, which can be used directly in factory.

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Machine specification of PVC/PU belt joint press machine:

Model	300	600	900	1200	1500	1800	2100
Effective length	305mm/12"	610mm/24"	914mm/36"	1219mm/48"	1524mm/60"	1829mm/72"	2360mm/90"
Effective width	130mm/4.7"	130mm/4.7"	130mm/4.7"	130mm/4.7"	130mm/4.7"	130mm/5.8"	130mm/5.8"
Weight lower part	11kgs	13kgs	18kgs	25.5kgs	32kgs	63.5kgs	73kgs
Weight upper part	10kgs	16kgs	20kgs	28.5kgs	30kgs	47.5kgs	67kgs
Total weight	21kgs	29kgs	38kgs	54kgs	62kgs	121kgs	142kgs
Overall height(mm)	220mm	225mm	225mm	225mm	225mm	255mm	255mm
MAX PRESSURE	2 Bar	2 Bar	2 Bar	2 Bar	2 Bar	2 Bar	2 Bar
PACKAGING DIMENSION (mm)	790430420	1090430420	1390430420	1720450430	2030470410	2212352280	2567352300
GROSS WEIGHT	46kgs	72kgs	89kgs	112kgs	134kgs	158kgs	184kgs

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Delivery:

We will use film to wrap the machine. then put into wooden box.
The normal package is wooden box.(Fumigation treatment).

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press

Our Services

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Customer visiting:

300-2100mm PU PVC Conveyor Belt Jointing Machine Air Cooling Splicing Press
